High-Flow Polyurethane Foaming Machine For Insulation Board
High Pressure Polyurethane Machine
Product ParametersParameterModel：HF-LPM-1A1B-LO (XJJF Series, Special for Block Foam)Components2-6 (Customizable for High Resilience/Memory Foam Formulas)Discharge Rate1-15kg/min (Non-standard available for different mold sizes)Material RatioA:B=1:3-3:1 (Wide range adjustment for all foam types)Tank CapacityTank A: 250-1000L;...
Key Features
- Precision process control
- Stable industrial production
- Flexible configuration options
- Full-cycle technical support
Product Parameters
| Parameter | Model：HF-LPM-1A1B-LO (XJJF Series, Special for Block Foam) |
|---|---|
| Components | 2-6 (Customizable for High Resilience/Memory Foam Formulas) |
| Discharge Rate | 1-15kg/min (Non-standard available for different mold sizes) |
| Material Ratio | A:B=1:3-3:1 (Wide range adjustment for all foam types) |
| Tank Capacity | Tank A: 250-1000L; Tank B: 200-800L (For large-volume continuous production) |
| Power | Customized according to discharge rate and temperature control |
| Mixing Head Speed | 2000-6000rpm (Variable frequency for different viscosity materials) |
| Metering Accuracy | ±0.5% (High-precision servo metering, eliminates ratio drift) |
| Weight | 2200kg (Excluding supporting equipment) |
| Warranty | 1-year whole machine warranty, lifetime technical support |
| Certification | ISO 9001:2015, Complies with EU Machinery Directive & Electrical Safety Standards |
Application Scenarios
This high-flow polyurethane foaming machine is specially developed for the production of various polyurethane thermal insulation products. It is widely used to manufacture floor heating panels, integrated wall panels, cold storage panels, insulated water tanks, water heater insulation layers, kitchen insulation boards, food steamer insulation parts and refrigerated truck insulation panels.
Core Advantages
High Production Efficiency & Consistent Product Quality
Equipped with dynamic high-flow injection system, the machine delivers materials rapidly and evenly into molds. The raw materials rise steadily inside the cavity and form foam with uniform cell structure. It greatly shortens the molding cycle and is perfectly compatible with continuous production lines. Compared with traditional low-pressure foaming machines, its production efficiency is improved by more than 50%, helping you cut time costs and expand production capacity.
Self-cleaning Mixing Head to Reduce Operational Costs
The high-pressure self-cleaning mixing head can finish automatic cleaning after operation. No frequent detergent is required, which saves consumable costs effectively. It also reduces downtime for manual cleaning and maintenance, and creates a cleaner working environment for your workshop.
Thorough Mixing & Low Material Waste
Raw materials collide and mix fully under high pressure. With precise ratio control, the machine ensures excellent mixing effect and greatly reduces defective products. The finished insulation boards feature fine and uniform foam cells with stable physical performance. It minimizes raw material loss and supports large-scale continuous production.
Intelligent Control & High Precision
Adopting PLC and microcomputer control system, the equipment can accurately regulate injection time, material ratio and working temperature. It is equipped with self-diagnosis and fault alarm functions to reduce manual operation errors. Stable operating parameters guarantee consistent quality for mass production.
Advanced Constant Temperature System
Material tanks adopt three-layer jacket stainless steel structure with circulating water for constant temperature. All high-pressure pipelines from tanks to mixing head are fitted with heating tapes and large-scale heat exchangers. The temperature deviation of raw materials is controlled within ±1℃. Stable temperature ensures flat finished boards and excellent thermal insulation performance that meets strict engineering standards.
Call to Action
If you are looking for reliable polyurethane foaming equipment for insulation board production, feel free to contact us for free quotation, technical support and customized solutions. Our professional team is ready to serve you.
