Polyurethane RRIM-PU Machine For Reinforced Reaction Injection Moulding
Moulds / Polyurethane Machines
Product ParametersParameterModel：HF-RRIM-PU-1A1BPouring Rate100～2000 g/sMix RatioPolyether: Isocyanate = 100:90~110Tank Capacity200L / 300L (Optional, Per Tank)Dosing Accuracy≤±0.3% (Full Dynamic Range)Tank Configuration1A1B Two-Component Independent Temp Control + Circulation StirringTemperature Control25～45℃Mixing Pressure150～200 barVenting SystemMold Negative Pressure...
Key Features
- Precision process control
- Stable industrial production
- Flexible configuration options
- Full-cycle technical support
Product Parameters
| Parameter | Model：HF-RRIM-PU-1A1B |
|---|---|
| Pouring Rate | 100～2000 g/s |
| Mix Ratio | Polyether: Isocyanate = 100:90~110 |
| Tank Capacity | 200L / 300L (Optional, Per Tank) |
| Dosing Accuracy | ≤±0.3% (Full Dynamic Range) |
| Tank Configuration | 1A1B Two-Component Independent Temp Control + Circulation Stirring |
| Temperature Control | 25～45℃ |
| Mixing Pressure | 150～200 bar |
| Venting System | Mold Negative Pressure Venting + High-Pressure Enhanced Homogenization |
| Cleaning System | High-Pressure Circulation Cleaning + Air Purging |
| Power | 15～22 kW |
| Control System | PLC + Touch Screen + Multi-Formula Storage |
| Application System | RRIM-PU Carbon Fiber/Fiberglass/High-Strength Fiber Reinforced Composite System |
| Warranty | 1 Year |
| Certification | CE, ISO9001 |
Application Scenarios
Specially designed for RRIM (Reinforced Reaction Injection Moulding) process, widely used in automotive structural parts, agricultural machinery heavy-duty parts, large engineering structural parts, high-end marine accessories and other fields. Compatible with carbon fiber, glass fiber and various high-strength fiber reinforced polyurethane materials, it meets the core requirements of high strength, high toughness, impact resistance and wear resistance, suitable for mass production and customized processing in various industries.
Core Advantages
Professional RRIM reinforced reaction injection molding process, high-pressure homogeneous mixing, uniform fiber dispersion, product strength and toughness far exceed ordinary RIM products, suitable for heavy-duty and impact-resistant scenarios.
Accurate two-component metering and proportioning, error ≤±0.3%, no delamination and defects in finished products, strong molding stability, greatly improving yield rate.
Adjustable large-flow output, compatible with integral molding of large structural parts and pouring of small precision reinforced parts, strong equipment versatility.
Intelligent multi-formula storage and switching, suitable for different fiber reinforced raw material ratios, easy to operate, meeting the needs of multi-category flexible production.
Product Parameters
| Parameter | Model：HF-RRIM-PU-1A1B |
|---|---|
| Pouring Rate | 100～2000 g/s |
| Mix Ratio | Polyether: Isocyanate = 100:90~110 |
| Tank Capacity | 200L / 300L (Optional, Per Tank) |
| Dosing Accuracy | ≤±0.3% (Full Dynamic Range) |
| Tank Configuration | 1A1B Two-Component Independent Temp Control + Circulation Stirring |
| Temperature Control | 25～45℃ |
| Mixing Pressure | 150～200 bar |
| Venting System | Mold Negative Pressure Venting + High-Pressure Enhanced Homogenization |
| Cleaning System | High-Pressure Circulation Cleaning + Air Purging |
| Power | 15～22 kW |
| Control System | PLC + Touch Screen + Multi-Formula Storage |
| Application System | RRIM-PU Carbon Fiber/Fiberglass/High-Strength Fiber Reinforced Composite System |
| Warranty | 1 Year |
| Certification | CE, ISO9001 |
Application Scenarios
Specially designed for RRIM (Reinforced Reaction Injection Moulding) process, widely used in automotive structural parts, agricultural machinery heavy-duty parts, large engineering structural parts, high-end marine accessories and other fields. Compatible with carbon fiber, glass fiber and various high-strength fiber reinforced polyurethane materials, it meets the core requirements of high strength, high toughness, impact resistance and wear resistance, suitable for mass production and customized processing in various industries.
Core Advantages
Professional RRIM reinforced reaction injection molding process, high-pressure homogeneous mixing, uniform fiber dispersion, product strength and toughness far exceed ordinary RIM products, suitable for heavy-duty and impact-resistant scenarios.
Accurate two-component metering and proportioning, error ≤±0.3%, no delamination and defects in finished products, strong molding stability, greatly improving yield rate.
Adjustable large-flow output, compatible with integral molding of large structural parts and pouring of small precision reinforced parts, strong equipment versatility.
Intelligent multi-formula storage and switching, suitable for different fiber reinforced raw material ratios, easy to operate, meeting the needs of multi-category flexible production.
Application details are configured according to the material, product, and production process.
Haifeng provides process evaluation, equipment configuration, commissioning, and lifecycle technical support.
