Polyurethane Elastomer Casting Machine For Construction Road
Elastomer Polyurethane Machine
Product ParametersParameterModel：HF-CPUE-2A2B-Cons-RoadPouring Rate100～1800 g/sRaw Material RatioPolyurethane Prepolymer : BDO Curing Agent = 100:4~7Tank Capacity220 / 300 LMixing Head Speed6000～10000 r/minDynamic Metering Accuracy≤±0.5% (Full range)Tank Configuration2A2B two-component + wear-resistant additive tankMaterial Temperature ControlTank...
Key Features
- Precision process control
- Stable industrial production
- Flexible configuration options
- Full-cycle technical support
Product Parameters
| Parameter | Model：HF-CPUE-2A2B-Cons-Road |
|---|---|
| Pouring Rate | 100～1800 g/s |
| Raw Material Ratio | Polyurethane Prepolymer : BDO Curing Agent = 100:4~7 |
| Tank Capacity | 220 / 300 L |
| Mixing Head Speed | 6000～10000 r/min |
| Dynamic Metering Accuracy | ≤±0.5% (Full range) |
| Tank Configuration | 2A2B two-component + wear-resistant additive tank |
| Material Temperature Control | Tank A: 30~80℃; Tank B(BDO): 25~50℃ |
| Pouring Pressure | 0.8～2.5 MPa |
| Cleaning System | High-pressure circulation cleaning + air purge cleaning |
| Power | 7.5～15 kW |
| Control System | PLC + touch screen + multi-formula storage |
| Applicable System | Polyurethane Elastomer System |
| Warranty | 1 year |
| Certifications | CE, ISO9001, Highway Engineering Certification |
Application Scenarios
Specially designed for polyurethane elastomer pouring of construction road engineering, suitable for road leveling, crack sealing, damage repair and waterproof layer pouring. It meets the core requirements of fast curing, wear resistance, rolling resistance and strong bonding, can withstand construction vehicle rolling, outdoor temperature changes and rain erosion, and firmly bonds with asphalt/concrete roads to prevent crack expansion and water intrusion, improve road flatness and service life, adapt to large-scale efficient construction, and shorten closed maintenance time.
Core Advantages
2A2B configuration with wear-resistant additives, excellent wear and rolling resistance, can withstand heavy construction vehicle loads, suitable for high-load road conditions.
BDO fast curing formula, fast room temperature curing and short maintenance time, without delaying construction progress and road traffic.
Precise pouring is suitable for wide cracks and large-area leveling, full filling without voids, high road flatness and stable construction quality.
The machine is easy to move and clean, suitable for complex construction site environments, with precise temperature control and metering to ensure construction consistency.
Product Parameters
| Parameter | Model：HF-CPUE-2A2B-Cons-Road |
|---|---|
| Pouring Rate | 100～1800 g/s |
| Raw Material Ratio | Polyurethane Prepolymer : BDO Curing Agent = 100:4~7 |
| Tank Capacity | 220 / 300 L |
| Mixing Head Speed | 6000～10000 r/min |
| Dynamic Metering Accuracy | ≤±0.5% (Full range) |
| Tank Configuration | 2A2B two-component + wear-resistant additive tank |
| Material Temperature Control | Tank A: 30~80℃; Tank B(BDO): 25~50℃ |
| Pouring Pressure | 0.8～2.5 MPa |
| Cleaning System | High-pressure circulation cleaning + air purge cleaning |
| Power | 7.5～15 kW |
| Control System | PLC + touch screen + multi-formula storage |
| Applicable System | Polyurethane Elastomer System |
| Warranty | 1 year |
| Certifications | CE, ISO9001, Highway Engineering Certification |
Application Scenarios
Specially designed for polyurethane elastomer pouring of construction road engineering, suitable for road leveling, crack sealing, damage repair and waterproof layer pouring. It meets the core requirements of fast curing, wear resistance, rolling resistance and strong bonding, can withstand construction vehicle rolling, outdoor temperature changes and rain erosion, and firmly bonds with asphalt/concrete roads to prevent crack expansion and water intrusion, improve road flatness and service life, adapt to large-scale efficient construction, and shorten closed maintenance time.
Core Advantages
2A2B configuration with wear-resistant additives, excellent wear and rolling resistance, can withstand heavy construction vehicle loads, suitable for high-load road conditions.
BDO fast curing formula, fast room temperature curing and short maintenance time, without delaying construction progress and road traffic.
Precise pouring is suitable for wide cracks and large-area leveling, full filling without voids, high road flatness and stable construction quality.
The machine is easy to move and clean, suitable for complex construction site environments, with precise temperature control and metering to ensure construction consistency.
Application details are configured according to the material, product, and production process.
Haifeng provides process evaluation, equipment configuration, commissioning, and lifecycle technical support.
