Polyurethane Foam Pouring Machine For General Foam
Low Pressure Polyurethane Machine
Product ParametersParameterModel：HF-Sponge-2A2B-GENPouring Rate100–2500 g/s (High/low flow for general foam, adjustable)Raw Material RatioPolyether polyol : Isocyanate (TDI/MDI) = 100:80–110Tank Capacity220 / 300 LMixing Head Speed4000–8000 r/minDynamic Metering Accuracy≤±0.5% (Full range)Tank Configuration2A2B main tanks...
Key Features
- Precision process control
- Stable industrial production
- Flexible configuration options
- Full-cycle technical support
Product Parameters
| Parameter | Model：HF-Sponge-2A2B-GEN |
|---|---|
| Pouring Rate | 100–2500 g/s (High/low flow for general foam, adjustable) |
| Raw Material Ratio | Polyether polyol : Isocyanate (TDI/MDI) = 100:80–110 |
| Tank Capacity | 220 / 300 L |
| Mixing Head Speed | 4000–8000 r/min |
| Dynamic Metering Accuracy | ≤±0.5% (Full range) |
| Tank Configuration | 2A2B main tanks + functional additive tank |
| Material Temperature Control | Tank A: 25–50℃; Tank B: 20–40℃ |
| Foaming Pressure | 0.8–2.0 MPa |
| Cleaning System | High-pressure circulating cleaning + air purge cleaning |
| Power | 7.5–15 kW |
| Control System | PLC + touch screen + multi-formula storage |
| Warranty | 1 year |
| Certifications | CE, ISO9001, RoHS 2.0 |
Application Scenarios
Specially built for general polyurethane foam pouring molding, widely suitable for foam production in furniture, automotive interiors, packaging, sports equipment and other industries. It flexibly supports flexible, semi-rigid and rigid foam process switching, meeting diverse production needs of foam density and hardness in different industries.
Core Advantages
2A2B main tanks with functional additive tank, quickly switch flame retardant, antistatic and other functional formulas, greatly expanding application scenarios.
Wide-flow precise pouring design, perfectly suitable for large mold production, effectively improving product qualification rate and production stability.
Multi-formula flexible compatible system, no core parts replacement for foam switching, one-key operation improves line efficiency.
Dual guarantee of precise temperature control and dynamic metering, long-hour continuous operation, stably meeting mass order delivery.
Product Parameters
| Parameter | Model：HF-Sponge-2A2B-GEN |
|---|---|
| Pouring Rate | 100–2500 g/s (High/low flow for general foam, adjustable) |
| Raw Material Ratio | Polyether polyol : Isocyanate (TDI/MDI) = 100:80–110 |
| Tank Capacity | 220 / 300 L |
| Mixing Head Speed | 4000–8000 r/min |
| Dynamic Metering Accuracy | ≤±0.5% (Full range) |
| Tank Configuration | 2A2B main tanks + functional additive tank |
| Material Temperature Control | Tank A: 25–50℃; Tank B: 20–40℃ |
| Foaming Pressure | 0.8–2.0 MPa |
| Cleaning System | High-pressure circulating cleaning + air purge cleaning |
| Power | 7.5–15 kW |
| Control System | PLC + touch screen + multi-formula storage |
| Warranty | 1 year |
| Certifications | CE, ISO9001, RoHS 2.0 |
Application Scenarios
Specially built for general polyurethane foam pouring molding, widely suitable for foam production in furniture, automotive interiors, packaging, sports equipment and other industries. It flexibly supports flexible, semi-rigid and rigid foam process switching, meeting diverse production needs of foam density and hardness in different industries.
Core Advantages
2A2B main tanks with functional additive tank, quickly switch flame retardant, antistatic and other functional formulas, greatly expanding application scenarios.
Wide-flow precise pouring design, perfectly suitable for large mold production, effectively improving product qualification rate and production stability.
Multi-formula flexible compatible system, no core parts replacement for foam switching, one-key operation improves line efficiency.
Dual guarantee of precise temperature control and dynamic metering, long-hour continuous operation, stably meeting mass order delivery.
Application details are configured according to the material, product, and production process.
Haifeng provides process evaluation, equipment configuration, commissioning, and lifecycle technical support.
