Polyurethane Low-Pressure Machine For Cold Storage Rigid Foam
Low Pressure Polyurethane Machine
Product ParametersParameterModel：HF-LPM-2A2B-R-ColdStoragePouring Rate300–6000 g/sRaw Material Ratio1:1~1:3 continuously adjustableTank Capacity120/220/500/1000LMixing Head Speed10000–15000 r/minMetering Accuracy≤±1.0%(Full range)Tank Configuration2A2B four-tank multi-formula systemMaterial Temperature Control20~60℃ precise temperature controlCleaning SystemAutomatic air-purge + pipeline circulating cleaning (solvent-free, eco-friendly)Power15~22kWControl SystemPLC...
Key Features
- Precision process control
- Stable industrial production
- Flexible configuration options
- Full-cycle technical support
Product Parameters
| Parameter | Model：HF-LPM-2A2B-R-ColdStorage |
|---|---|
| Pouring Rate | 300–6000 g/s |
| Raw Material Ratio | 1:1~1:3 continuously adjustable |
| Tank Capacity | 120/220/500/1000L |
| Mixing Head Speed | 10000–15000 r/min |
| Metering Accuracy | ≤±1.0%(Full range) |
| Tank Configuration | 2A2B four-tank multi-formula system |
| Material Temperature Control | 20~60℃ precise temperature control |
| Cleaning System | Automatic air-purge + pipeline circulating cleaning (solvent-free, eco-friendly) |
| Power | 15~22kW |
| Control System | PLC + touch screen + multi-formula storage |
| Warranty | 1 year |
| Certifications | CE, ISO9001 |
Application Scenarios
Specially designed for polyurethane rigid foam insulation of cold storage, cold chain warehouses, cold storage boards and refrigerated carriages. It meets large-size and high-thickness filling needs, stably guarantees high thermal insulation, flame retardancy and low thermal conductivity, suitable for large-scale cold chain production.
Core Advantages
2A2B four-tank multi-formula system, perfectly suitable for complex cold storage rigid foam formulas, stable supply without cross-contamination.
Ultra-high flow wide-range pouring, suitable for cold storage boards and large boxes, full molding without defects, improving insulation quality.
Special high-speed mixing + precise temperature control for rigid foam, high closed cell rate and low thermal conductivity, long-term stable insulation.
Solvent-free eco-friendly cleaning system, stable and reliable operation, meeting long-hour continuous production needs.
Product Parameters
| Parameter | Model：HF-LPM-2A2B-R-ColdStorage |
|---|---|
| Pouring Rate | 300–6000 g/s |
| Raw Material Ratio | 1:1~1:3 continuously adjustable |
| Tank Capacity | 120/220/500/1000L |
| Mixing Head Speed | 10000–15000 r/min |
| Metering Accuracy | ≤±1.0%(Full range) |
| Tank Configuration | 2A2B four-tank multi-formula system |
| Material Temperature Control | 20~60℃ precise temperature control |
| Cleaning System | Automatic air-purge + pipeline circulating cleaning (solvent-free, eco-friendly) |
| Power | 15~22kW |
| Control System | PLC + touch screen + multi-formula storage |
| Warranty | 1 year |
| Certifications | CE, ISO9001 |
Application Scenarios
Specially designed for polyurethane rigid foam insulation of cold storage, cold chain warehouses, cold storage boards and refrigerated carriages. It meets large-size and high-thickness filling needs, stably guarantees high thermal insulation, flame retardancy and low thermal conductivity, suitable for large-scale cold chain production.
Core Advantages
2A2B four-tank multi-formula system, perfectly suitable for complex cold storage rigid foam formulas, stable supply without cross-contamination.
Ultra-high flow wide-range pouring, suitable for cold storage boards and large boxes, full molding without defects, improving insulation quality.
Special high-speed mixing + precise temperature control for rigid foam, high closed cell rate and low thermal conductivity, long-term stable insulation.
Solvent-free eco-friendly cleaning system, stable and reliable operation, meeting long-hour continuous production needs.
Application details are configured according to the material, product, and production process.
Haifeng provides process evaluation, equipment configuration, commissioning, and lifecycle technical support.
