Polyurethane Low Pressure Machine For Safety Shoes
Low Pressure Polyurethane Machine
Product ParametersParameterModel：HF-LPM-1A1B-F (2-6 components customizable)Dosing Rate30~150g/sMix RatioA:B = 100:35~85Tank Capacity200LPower12kWMixing Head SpeedPouring Speed: 4000~10000rpm (Adjustable) Injection Speed: 10000~18000rpm (Adjustable)Dosing Accuracy±0.5%Weight1000kgWarranty1 YearCertificationCE, EN 60204-1, ISO9001Application ScenariosIt is widely used in the field of...
Key Features
- Precision process control
- Stable industrial production
- Flexible configuration options
- Full-cycle technical support
Product Parameters
| Parameter | Model：HF-LPM-1A1B-F (2-6 components customizable) |
|---|---|
| Dosing Rate | 30~150g/s |
| Mix Ratio | A:B = 100:35~85 |
| Tank Capacity | 200L |
| Power | 12kW |
| Mixing Head Speed | Pouring Speed: 4000~10000rpm (Adjustable) Injection Speed: 10000~18000rpm (Adjustable) |
| Dosing Accuracy | ±0.5% |
| Weight | 1000kg |
| Warranty | 1 Year |
| Certification | CE, EN 60204-1, ISO9001 |
Application Scenarios
It is widely used in the field of shoe material manufacturing, suitable for pouring and injection molding of polyurethane (PU) foamed products. It is specially used for the production of labor protection shoes (safety shoes), and can also produce PU shoe materials such as sandals, slippers and beach shoes.
Core Advantages
High automation, only 2-4 operators required, optional automatic manipulator, easy to control with adjustable speed.
Dosing accuracy up to ±0.5%, ensuring stable hardness, wear resistance and impact resistance of safety shoes.
Energy-saving low-pressure operation, low wear, easy maintenance and long service life of core parts.
Supports two-color & dual-density integrated molding, suitable for mass production of safety shoes with stable quality.
Product Parameters
| Parameter | Model：HF-LPM-1A1B-F (2-6 components customizable) |
|---|---|
| Dosing Rate | 30~150g/s |
| Mix Ratio | A:B = 100:35~85 |
| Tank Capacity | 200L |
| Power | 12kW |
| Mixing Head Speed | Pouring Speed: 4000~10000rpm (Adjustable) Injection Speed: 10000~18000rpm (Adjustable) |
| Dosing Accuracy | ±0.5% |
| Weight | 1000kg |
| Warranty | 1 Year |
| Certification | CE, EN 60204-1, ISO9001 |
Application Scenarios
It is widely used in the field of shoe material manufacturing, suitable for pouring and injection molding of polyurethane (PU) foamed products. It is specially used for the production of labor protection shoes (safety shoes), and can also produce PU shoe materials such as sandals, slippers and beach shoes.
Core Advantages
High automation, only 2-4 operators required, optional automatic manipulator, easy to control with adjustable speed.
Dosing accuracy up to ±0.5%, ensuring stable hardness, wear resistance and impact resistance of safety shoes.
Energy-saving low-pressure operation, low wear, easy maintenance and long service life of core parts.
Supports two-color & dual-density integrated molding, suitable for mass production of safety shoes with stable quality.
Application details are configured according to the material, product, and production process.
Haifeng provides process evaluation, equipment configuration, commissioning, and lifecycle technical support.
